Display
-
4 in. full-color LCD touchscreen
-
540 x 540 pixel display
Dimensions
Thermostat
-
Height: 103.89 mm (4.09 in.)
-
Width: 103.89 mm (4.09 in.)
-
Depth: 25.9 mm (1.02 in.)
Trim plate
-
Height: 143.5 mm (5.65 in.)
-
Width: 159.9 mm (6.29 in.)
-
Depth: 7.71 mm (0.3 in.)
Power Extender Kit*
-
Length: 62 mm (2.4 in.)
-
Width: 62 mm (2.4 in.)
-
Depth: 23 mm (0.9 in.)
-
*Optional for installation
Colors
-
Black front, die cast metal frame – zinc alloy
Thermostat sensors
-
Temperature
-
Humidity
-
Occupancy (Radar)
-
Proximity (Radar)
Compatibility
-
Works with most 24VAC HVAC equipment, including conventional furnaces and air conditioners (2H/2C), heat pumps (2H/2C + 2 stage AUX heat), boilers, and PTACs or fan coil units with up to 3 fan speeds. One 1-wire accessory or one 2-wire accessory support for humidifiers, dehumidifiers, and ventilators (HRV/ERV).
HVAC accessory support
-
One 1-wire acc. or one 2-wire accessory. Control an accessory HVAC device like a humidifier, dehumidifier, or ventilation device.
Wire Terminals
-
Rc
-
G
-
Y1
-
Y2
-
OB
-
PEK+
-
C
-
Rh
-
W1
-
W2
-
ACC-
-
ACC+
Connectivity & security
-
Dual-band Wi-Fi: 802.11 b/g/n @ 2.4GHz, 802.11 a/n/ac @ 5GHz
-
Bluetooth 5.0
-
WPA, WPA2, WPA3 encryption methods
-
DHCP (dynamic) or static IP addressing
-
168-bit SSL encryption
-
915MHz radio
Works with
-
Apple HomeKit, Amazon Alexa, Samsung SmartThings, IFTTT, and more.
Bandwidth
-
15-20 MB/month (dependent on Alexa Voice Service usage)
Power consumption
-
Up to 3.5 VA
Powering methods
-
Wired 24VAC through terminals C and Rc.
-
Power Extender Kit enables you to reliably power your thermostat without having to run a fifth wire.
Sustainability
-
Recycled packaging
-
Mercury-free
-
Arsenic-free
-
PVC-free
-
ROHS compliant
Temperature range
-
Desired Temperature: 45° to 92°F (7° to 33°C)
-
Display: 40° to 100°F (5° to 37°C)
-
Sensitivity: +/− 1°F (+/− 0.5°C)
-
Operating: 14° to 122°F (-10° to 50°C)
Humidity range
-
Display: 20% to 90%
-
Sensitivity: +/− 5%
-
Operating: 5% to 95% RH (non-condensing)
Storage
-
−31° to 113°F (−35° to 45°C)
-
5% to 95% RH (non condensing)
