Specifications
- Voltage
- mV to 30 Vac 50/60 Hz
- Stages Heat/Cool
- Single Stage – 1H/0C
- Style
- Vertical
- Typical Applications
- Gas/Oil/Electric, but does not control fan on a call for heat
- 3-Wire Zone Valve Connection
- No
- Millivolt Compatible
- Yes
- Heat Pump (No Auxiliary Heat)
- No
- Electric Heat Strip
- No
- Accessories
- Includes temperature locking or limiting Kit; Wallplate (no system switch); Switched subbase Heat-Off
- Electric Heat Fan Control (Systems that Require (G terminal) on Call for Heat)
- No
- U.S. Only or Canadian Only Model
- U.S. Only
- Control Range
- 50 to 90 deg. F
- Terminals
- RH, W
- Overall Dimensions
- 4.5 in. H X 3.25 in. W X 1.63 in. D
- Heat Anticipator
- Adjustable from 0.15 to 1.2 Amps
- Control Range
- 50 to 90 deg. F
- Terminals
- RH, W
- Dimensions
- 4.5 in. H X 3.25 in. W X 1.63 in. D
- Heat Anticipator
- Adjustable from 0.15 to 1.2 Amps
