Model
-
24000 Cooling Only
Type
-
cooling only
Control type
-
Remote Controller
Rated cooling capacity(T1)
-
22800 Btu/h
Rated cooling capacity(T3)
-
20248 Btu/h
Rated cooling capacity(T4)
-
18920 Btu/h
Indoor noise level at cooling
-
Super
-
53 dB(A)
-
-
High
-
51 dB(A)
-
-
Med.
-
49 dB(A)
-
-
Low
-
47 dB(A)
-
-
Quiet
-
45 dB(A)
-
Outdoor noise level
-
55 dB(A)
Climate type
-
T3
Power supply
-
220~240V1 Phase/ 50Hz
Voltage Range
-
198~264 V
Rated Power input
-
Cooling(T1)
-
1898 W
-
-
Cooling(T3)
-
2249 W
-
-
Cooling(T4)
-
2275 W
-
Max Current
-
Cooling(T1)
-
15.3 A
-
-
Cooling(T3)
-
15.3 A
-
-
Cooling(T4)
-
15.3 A
-
Max Power input
-
Cooling(T1)
-
2850 W
-
-
Cooling(T3)
-
2850 W
-
-
Cooling(T4)
-
2850 W
-
Refrigerant
-
R410A/1.10kg
Max. pipe length
-
15 m
Max.pipe hight
-
5 m
Max Temperature
-
55 ℃
Net dimensions (W x Dx H)
-
Indoor
-
1186x340x258 mm
-
-
Outdoor
-
920×380×699 mm
-
Net weight
-
Indoor
-
18 kg
-
-
Outdoor
-
43 kg
-
Packing dimensions (W x D x H)
-
Indoor
-
1262×420×337 mm
-
-
ODU(W/O piping)
-
960x400x732 mm
-
Gross weight
-
Indoor
-
22 kg
-
-
ODU(W/O piping)
-
47 kg
-
