Model
-
CS/CU-TU18WKY-5
18000 Cooling Only
Type
-
cooling only
Control type
-
Remote Controller
Rated cooling capacity(T1)
-
Btu/h
-
18200
-
-
W
-
5334
-
Rated cooling capacity(T3)
-
Btu/h
-
15250
-
-
W
-
4469
-
EER for cooling(T1)
-
Btu/h-W
-
12.18
-
-
W/W
-
3.56
-
EER for cooling(T3)
-
Btu/h-W
-
8.52
-
-
W/W
-
2.50
-
Moisture removal
-
Liters/h
-
1.2
-
Indoor Noise level
-
High
-
dB(A)
-
48
-
-
-
Low
-
dB(A)
-
43
-
-
Outdoor noise level
-
dB(A)
-
53
-
Power supply
-
230V, 1-phase
Voltage Range
-
V
-
220-240
-
Rated Current
-
Cooling(T1)
-
A
-
6.9
-
-
-
Cooling(T3)
-
A
-
8.2
-
-
Power input
-
Cooling(T1)
-
W
-
1500
-
-
-
Cooling(T3)
-
W
-
1790
-
-
Running Current
-
Cooling(T1)
-
A
-
6.9
-
-
-
Cooling(T3)
-
A
-
8.2
-
-
Refrigerant
-
kg
-
R-32/ 855gms
-
Refrigerant Pipe Diameter
-
Liquid Side
-
mm
-
6.35
-
-
inch
-
1/4″
-
-
-
Gas Side
-
mm
-
12.7
-
-
inch
-
1/2″
-
-
Max. pipe length
-
15m
Max.pipe hight
-
7.5m
Max Temperature
-
℃
-
54
-
Net dimensions (WxDxH)
-
Indoor
-
mm
-
1070×235×290
-
-
-
Outdoor
-
mm
-
824×299×619
-
-
Net weight
-
Indoor
-
kg
-
12
-
-
-
Outdoor
-
kg
-
31
-
-
Packing dimensions (W x D x H)
-
Indoor
-
mm
-
1160 x 281 x 369
-
-
-
ODU(W/O piping)
-
mm
-
970 x 416 x 700
-
-
Gross weight
-
Indoor
-
kg
-
14
-
-
-
ODU(W/O piping)
-
kg
-
35
-
-
