Model#
-
CS/CU-PN18YKF
Type
-
Cool Only
Compressor
-
Fixed Speed, Rotary
Refrigerant
-
R32
Cooling Capacity (Btu/h) (T1/T3)
-
18300/16000
Heating Capacity (Btu/h) (T1/T3)
-
–
Electrical Data (T1/T3)
-
Voltage (V)
-
230-240
-
-
Running current (A)
-
6.7/8
-
-
Power input (W)
-
1510/1810
-
-
EER (Btu/hW) (T1/T3)
-
12.12/8.84
-
Pipe Extension (m)
-
Maximum Pipe Length
-
40
-
-
Maximum Height Difference
-
30
-
Operating (Ambient) Temperature
-
55°C
Net Dimension (IDU / ODU)
-
H x W x D (mm)
-
295 x 1040 x 244/619 x 824 x 299
-
Gross Dimension (IDU / ODU)
-
314 x 11148 x 383/717 x 999 x 446
Net / Gross Weight (Kg)
-
IDU / ODU
-
12/39 (N)
14/44 (G)
-
Country of Origin
-
Malaysia
